Keychain
The idea of keychain is to simplify the access to data in an Anvil App that is using
routing by using data keys that are consistent between page, client and server. Keychain automatically fetches any cached data on the client side then requests any missing data from the server in a single round-trip server call.
What does Keychain do?
Keychain takes the common usage of data binding from a form’s item attribute ie. self.item['name'] and extends this to defining what data a form requires, caching, and retriving missing data from the server. The data key name in this example, is data definition throughout these places.
Keychain automatically finds the data from loader_args['nav_context'], keyring’s client cache, and finally, requesting from the server.
When requesting data from the server, the page retrieves all missing data in a single server call reducing load time. However, on the server side, data is not defined in a single server function, and the user is free to reduce each function to the smallest realistic return scope. Keychain, automatically compiles the necessary server functions to return the requested data keys to the client.
Keychain allows data permission to be defined at the key level and allows for redirections if a client tries to access data without the necessary permissions.
Example
client/routes.py
from routing.router import Route, Redirect
from keychain.client import AutoLoad, initialize_cache
class HomeRoute(AutoLoad):
path = "/home"
form = "Pages.Home"
fields = ["first_load", "the answer to everything"]
strict = False
class AccountRoute(AutoLoad):
path = "/account"
form = "Pages.Account"
strict = False
fields = ["first_load", "the answer to life", "name", "email"]
Here we define what data fields are required for each page. Notice that "first_load" is reused between pages. Keychain will automatically cache the reused field for reuse between the pages.
server/client_data.py
import anvil.server
import anvil.user
from keychain.server import register_data_request, Flatten
import time
def admin_check():
user = anvil.users.get_user()
return user['role'] == 'admin'
@register_data_request(
field=[f"the answer to {x}" for x in ["everything", "life", "the universe"]],
permission=admin_check
)
def get_the_answer(*args, **loader_args):
print("get_the_answer", loader_args["params"])
return 42
@register_data_request(field=["name", "email", "phone"])
def get_account_data(*args, **loader_args):
"""Allow multiple fields to resolve to the same function for use cases like this.
Here I'm using the Flatten marker that will then be flattened in the data reponse.
This might be a complication that without much benefit.
This could be interesting if we namespaced keys...
ie.
'account' -> {'name': name, 'email': email, 'phone': phone}
'account.email' -> email
"""
print("get_account_data", loader_args.get("params", None))
return Flatten(name="Arther", email="arther@galaxyguides.com", phone="987-654-3210")
@register_data_request(field=["first_load", "server_time"])
def get_time(*args, **loader_args):
print("get_time", loader_args.get("params", None))
return time.time()
Each of the fields pages are requesting should have a matching function on the server. These functions are registered by adding @register_data_request decorator. Adding a permission to the registration forces a function call before the data is accessed.
The server functions will have the data applied to the key that is requested. So, in this case, "first_load" was the request field and the resulting dict key not "server_time".
Flatten allows you to update the request dict rather than adding a sub dict. This behavior can be seen in the get_account function. Requesting "account" without Flatten would result in:
{
"account": {
"name": "Arther",
"email": "arther@galaxyguides.com",
"phone": "987-654-3210"
}
}
with Flatten the result is not nested under "account"
{
"name": "Arther",
"email": "arther@galaxyguides.com",
"phone": "987-654-3210"
}
/client/Pages.Home
from ._anvil_designer import HomeTemplate
from routing import router
class Home(HomeTemplate):
def __init__(self, routing_context: router.RoutingContext, **properties):
self.routing_context = routing_context
properties["item"] = routing_context.data
self.init_components(**properties)
Using the standard routing form boilerplate means that you will have a self.item that has a dict with keys that align with the defined routes fields.
Now, with the fields the page requires and the function on the server registered, all required data will be available to the form in the routing_context.data as a dict.
self.item = {
"first_load": 123456789,
"the answer to everything": 42,
}
Fields vs. Keys
I make a distinction between the two because of an additional feature within Keychain. Conceptually, keys are used for storage and retrieval and fields are key templates. In most cases, these are the same. The examples presented so far do not have any difference between the field and the key
However, if we wanted the ability to retrieve and cache data that is associated with some id this is where the distinction becomes useful.
Let’s say we have some "private" field that is associated with a private_id=1234. We need to be able to request ("private", 1234) and we also need to store a unique instance of "private" for this private_id. Using fields you would define the field as "private_{private_id}". The field is now generic to the route, but the data can be retrieved and cached using your defined key which in this case "private_1234". The attributes are automatically filled from loader_args["params"]. To get the key from the field, Keychain does a simple string format:
key = field.format(**loader_args["params"])
So, any number of params can be used to create a unique key for storage and retrieval. The name_{a} is simply an example and any string can be used as long as it forms a unique key that is useful to you. name a:{a} b:{b}, name{a}{b}, {a}name{b}, … get crazy.
# client/routes.py
class PrivateIdRoute(AutoLoad):
path = "/private/:private_id"
form = "Pages.Private"
fields = ["private_{private_id}"]
Here we use the path’s private_id within the field. Now, there is a slight annoyance with this. The self.item would have the key "private_{private_id}". When using nav_context to send data during navigation you would also need to use this key. However, you can remap keys to simplify this case:
# client/routes.py
class PrivateIdRoute(AutoLoad):
path = "/private/:private_id"
form = "Pages.Private"
global_fields = ["private_{private_id}"]
remap_fields = {
"private_{private_id}": "private",
}
Server functions are registered using the field="private_{private_id}" and you have access to loader_args.
# server/client_data.py
@register_data_request(field="private_{private_id}")
def get_private_value(*args, **loader_args):
return f"Private Value:{3 * str(loader_args['params'].get('private_id'))}"
Demo App
Checkout the demo app for Keychain:
Clone with Keychain
Clone in Anvil without keychain clone
Clone without Keychain
Clone in Anvil with keychain clone
Using
Clone Keychain
App ID:
UESVUJKDGQULTT5M
